Fusionride Columbus radar is a high-performance 77GHz 4T4R radar with the latest generation of frequency domain MIMO mode on the waveform, which can achieve longer detection range and larger FOV.

FusionRide Picasso 4D lmaging Radar 6X8 NXP is a 77GHz band 6-transmitter, 8-receiver radar with a maximum detection range of 350 meters, combining high range and angle accuracy. It supports multiple outputs such as radar point cloud and radar tracking target, which is suitable for vehicle integration. Operating temperature -40~+85℃, meets ASIL B functional safety, provides accurate and reliable environment sensing capability for intelligent driving.

FusionRide 24GHz Two-Wheeler BSD Radar features a compact size (61×45.5×13mm) and lightweight design (<100g). It outputs radar point clouds and target data, supporting functions such as lane change assistance with a detection range of 0.65 to 50 meters. Designed for low power consumption and full frequency band compliance, this radar enhances safety for motorcycle and e-bike systems.

FusionRide 77GHz Two Wheeler BSD Radar High Performance，Compact size (52 x 51 x 15.5 mm), weighing<80 g. 77GHz band, detection distance up to 100m, support point cloud, target output, to achieve lane-change assistance and other functions for two-wheeled vehicle travel to build a solid safety barrier.

FusionRide 77GHz Two Wheeler Rear Radar，Size (35×25×22mm), weight＜100g, 77GHz band, detection distance 70m. Output point cloud and target, realize the function of lane change assistance, blind zone monitoring, etc., suitable for 9 - 16V voltage, add wings for the safety of two-wheeled vehicles.

FusionRide Drone Obstacle Avoidance Radar，Designed for safe UAV flight. Compact size (50×60×5.5mm), weight<200g, easy to integrate, 24GHz band, detection range 1.5-60m, distance resolution 0.65m, speed range -50~50m/s. Horizontal field of view ±45°, vertical 30°, 50ms transmission cycle, real-time environment awareness. Horizontal field of view ±45°, vertical 30°, 50ms sending cycle, real-time environment awareness, 5V power supply, UART interface, 921600 baud rate, suitable for - 40~85℃ wide temperature range, support OTA upgrade, for UAV obstacle avoidance precision escort, make flight safer and smarter.

FusionRide Fall Detection Radar，Safeguard safety with advanced technology. The 60GHz operating frequency with FMCW modulation mode accurately covers the detection range of 5 meters. With a compact size (60×60×27 mm) and a weight of<200 grams, it fits easily into any scenario. It has the ability to output point clouds and identify human joint points, accurately judge the status of personnel and count the number of people, and the core "fall detection" function is sensitive and reliable. Operating temperature -20~ 50°C, humidity 5% - 95%, suitable for complex environments, 5V2A power supply, UART interface, 921600 baud rate to ensure efficient data transmission, WiFi wireless connection to expand application convenience, for family, elderly care and other scenarios to build a solid security line of defense.

FusionRide Super Sensor，Dimensions (76.5×47×25 mm), IP67 protection. The 60GHz band has a maximum detection distance of 20 meters, a horizontal field of view of 102°, and a vertical field of view of 67°. It can realize the functions of general obstacle detection, category recognition (pedestrian/pet, etc.), multi-target tracking, etc., with a depth resolution of 640x360@10fps, more than 2 million point clouds per second, and adapt to the environment of -30~65°C, providing accurate data for intelligent perception.

FusionRide Picasso 4D lmaging DlY Radar supports long range (350m), short range (125m) and customized modes, 6T8R transceiver architecture. It can output point cloud, tracking targets, etc. It can also flexibly configure waveform parameters, change parameters through UI, automatically verify the generated file, and output raw ADC data. Compact size, excellent protection and safety performance, suitable for diversified intelligent driving development needs, empowering innovative applications.

FusionRide Door Radar -Calterah 244 is a 4-transmitter 4-receiver radar based, output obstacle target position, door maximum openable angle . Compact size (72 × 22 × 10.3 mm), weight<35 grams, wide operating temperature range, low power consumption. With IP6K7 protection, functional safety up to ASIL B, door radar for door control scenarios to help accurate perception.
